Product features:
• 40 μ M InGaAsP/InP APD chip
• Low dark current, 0.95-1.25 μ M-band high response rate
• Linear/Geiger mode, low dark count, high single photon detection efficiency
• Integrated tail fiber, high quantum efficiency, high reliability
• Lidar, ranging, low light detection, high-speed laser communication
Precautions for use:
(1) During the use of the product, the positive and negative terminals of the thermoelectric cooler must not be reversed, otherwise it will affect the performance and service life of the product.
(2) The product uses a thermistor for temperature measurement, and the cooling effect is related to environmental temperature, power performance, and heat dissipation status.
(3) There is an electrostatic protection device installed on the pins of the product. During use, operators should wear an electrostatic wristband, take appropriate electrostatic protection measures, and then remove the electrostatic protection device and use the product.
(4) During storage and transportation, products should be equipped with electrostatic protection devices and stored in anti-static boxes.
(5) The product needs to be plugged and unplugged after power failure; When the product is not working, the power supply to the thermoelectric cooler should be stopped.
